PNC is a bank that provides financial services to BriteCore customers, such as PNC Lockbox. PNC Lockbox processes mail-in payments for carriers.
Note: While BriteCore doesn't directly interact with PNC services, it can consume data related to it.
The PNC Lockbox integration allows PNC to:
- Provide a dedicated PO box for mail-in payments.
- Process mail-in payments.
- Send BriteCore a payments file, which is automatically applied to the applicable policies.
Set up PNC Lockbox
- Contact PNC.
- Complete the required paperwork.
- Set up your PNC Lockbox.
- Obtain the following information from PNC:
- PNC Lockbox number
- Username
- Password
- Port number
- Once you have PNC Lockbox set up, contact BriteCore.
Configuration
Access the configuration settings
- In the BriteCore menu, select Settings.
- In the Settings menu, select Vendors.
- On the Vendors screen, under Check Scanning, select PNC Lockbox.
- Next to PNC Lockbox, select the edit icon .
- In the PNC Lockbox dialog box, complete the configuration settings.
Set up PNC Lockbox in BriteCore
- In the BriteCore menu, select Settings.
- In the Settings menu, select Vendors.
- On the Vendors screen, under Check Scanning, select PNC Lockbox.
- Next to PNC Lockbox, select the edit icon .
- In the PNC Lockbox dialog box, complete the following steps:
- Select Create Matchfile.
- Select Use legacy accounting.
- In the Customer Information box, type your PNC Lockbox number.
- In the Days for cancellation box, type the number of days for cancellation.
- In the Transfer Settings section, under Lockbox Server, select Test.
Note: Select Production only when you are in production.
- Select Export Matchfile.
- In the Username box, type your username.
- In the Port box, type the PNC Lockbox port number.
- In the Upload Type dropdown list, select SFTP.
- In the PNC Payment Settings section, ensure Require check number and Use normalized policy number are selected, and if they aren’t, select both of them.
Note: By default, Require check number and Use normalized policy number are selected.
- If applicable, select Allow duplicate payments.
- In the Payment notification email box, type the email address(es) of anyone who should receive payment notification emails.
Note: Use a comma-separated list to add multiple email addresses.
Key authorization
The PNC Lockbox integration requires key authorization, so you will need to:
- Generate a key.
- Send the public portion to PNC.
- Add the private portion to the BriteCore database.
BriteCore API
BriteCore's API endpoint:
- Allows customers to submit data extracted from a PNC Lockbox payment file.
- Applies the contained payments to the respective policies.
- Updates the internal payment accounting registry.
Payment coupons
Payment coupons are the bottom part of billing statements that insureds remove and mail in with their payments.
Scan line requirements
A scan line is a long string of numbers and letters located at the bottom of a payment coupon. The scan line contains information that can be scanned into the system. PNC requires scan lines to contain the following information:
- Policy number/ID
- Amount due
- Check digit
Note: Stock deliverables don’t include a check digit.
You will need to create and use custom templates/deliverables and have a developer update the scan line to include the check digit.
Example: Policy ID: HM-2021-6924 Amount due: $474.00 Check digit: 07 Scan line: 000004740000000HM2021692407 In the example scan line, you can see the policy ID, the amount due, and check digit:
- Policy ID: 000004740000000HM2021692407
- Amount due: 000004740000000HM2021692407
- Check digit: 000004740000000HM2021692407
Check digit
PNC requires scan lines to contain a check digit.
Note: BriteCore’s stock deliverables don’t include check digits.
Adding a check digit to a payment coupon scan line requires:
Note: BriteCore can make the custom deliverable look like the stock deliverable through HTML and jinja
Payment coupon testing
Once a developer adds a check digit to the payment coupon scan line on your custom deliverable template, you will need to use a BriteCore test site to send PNC 50 sample coupons to test the check digit. PNC requires you to send them 50 sample coupons with check digits. You can’t move forward with PNC until you get the deliverables set up enough for a test site.
Important: If you use a print vendor, PNC requires the print vendor to send them 50 sample coupons with check digits.
